Refrigerated Incubator SH-CH-81R

25℃ ~ 80℃

81(Liter)

- For incubation temperature 15ºC ~ 30ºC

- Durable structure against continuous operation

- Stainless Steel Internal Chamber with shelves
- Excellent temperature uniformity and accuracy

- Inner Glass Door installation

- Safety assurance with C.E conformity

  • Specification

  • Inquiry

  • This version of incubator comes with a high-powered refrigeration compressor. Its cooling temperature ranges from -5ºC to 60ºC. It is designed to conduct separated tests in high or low temperature. It is also capable of minimizing adjustment period from low to high or vice versa.


    - Stainless steel inner chamber

    - Accurate temp control

    - RS-485 or RS-232C interface

    - Water proof socket

    - Leveling caster

    - Safety devices

    - Digital controller

    - Inner glass door
  • Model SH-CH-81R
    Air Circulation type  Forced Air Circulation
    Temp Range  Ambient -25℃ to 80℃ (Ambient -45℉ to 176℉)  (Low limit -5℃)

    Time Range

    00.00 to 99HR 59MIN (MIN SEC) Selectable Digital Display
    Temp control Digital Microprocessor PID controller
    Temp Accuracy & Stability ±0.1

    Temp Uniformity

    ±0.5

    Capacity  81L
    Dimension Internal
    (W×D×H)
    450x400x450mm
    17.72x15.75x17.72"
    Dimension External
    (W×D×H)
    650x650x1250mm
    25.59x25.59x49.21"
    Weight 80 kg
    Material Internal Stainless Steel
    Material External Steel Plate With Powder Heating Coated
    Shelves 2 Supplied (17 Maximum)

    Water Proof Socket

    7A / 1EA
    Heater 1000W
    Electrical Requirements
    230V,50/60Hz, 1Φ
    4.6 A
    Cat. No. 50Hz (60Hz) CH81R230-50
    (CH81R230-60)

    • Accessory

    -Movable epoxy coated wire shelves 2EA


    • Option

    -Programmable Controller

    -Digital Recorder

    -2CH Hybrid Recorder

    -RS-485 interface

    -RS-232C interface


    • Safety Device

    -Automatic reset function incoming power cut

    -Buzzer on when set time arrived

    -Door open alarm

    -Electric leakage breaker

    -Over temp controller

    -Refrigerator over load protection



  • SH Scientific is an Advanced Laboratory Equipment Manufacturer
